Split Heat Pipe Solar Water Heater（Split Solar Water Heater ）
— Inner Tank: Stainless Steel 304 2B/316L
— Heat-exchange Coil: Double（Or Single） heat-exchange coil （SUS304/SUS316L/Red copper）
— Outer Tank: Galvanized steel (SUS201, SUS304, SUS316 are also available)
— Insulation layer: 50-100mm thick high density polyurethane foam
— Vacuum Tube: Three-target vacuum tube, anti-freezing heat pipe, Aluminium fin and heat-resisting silicon seal
— Heat-pipe Manifold: Red copper header Φ35X1.0mm, Aluminium alloy shell 2mm, high-density rockwool insulation
— Solar Pump Station & Expansion vessel: Pump station, high pressure expansion vessel 5L-50L
— Collector Bracket: Gray/ black aluminium alloy 1.8mm, universal bracket suitable for slope/ flat roof or wall installation
— Accessories: Thermostat electrical heater with regulator, Anode magnesium, T/P & Safety valve, copper connectors
— Rated Working Pressure: 7.0 Bar
— Anti-freezing Weather: < (-)40 ℃
Description：
The split pressurized solar water heater consists of pressurized water tank, heat pipe pressurized collector,working pump station, expansion tank, etc. It is suitable for high-end residences such as villas. The solar collector can be installed on the roof and the water tank can be installed in the attic or basement. It is popular in Europe and the United States. The water tank can also be connected to other heat sources such as heat pumps or gas boilers. System capacity range: 100-1000L.
Inner Tank：Stainless Steel 304 2B/316L
Heat-exchange Coil：Double（Or Single） heat-exchange coil （SUS304/SUS316L/Red copper）
Outer Tank：Galvanized steel (SUS201, SUS304, SUS316 are also available)
Insulation layer：50-100mm thick high density polyurethane foam
Vacuum Tube：Three-target vacuum tube, anti-freezing heat pipe, Aluminium fin and heat-resisting silicon seal
Heat-pipe Manifold：Red copper header Φ35X1.0mm, Aluminium alloy shell 2mm, high-density rockwool insulation
Solar Pump Station & Expansion vessel：Pump station, high pressure expansion vessel 5L-50L
Collector Bracket：Gray/ black aluminium alloy 1.8mm, universal bracket suitable for slope/ flat roof or wall installation
Accessories：Thermostat electrical heater with regulator, Anode magnesium, T/P & Safety valve, copper connectors
Rated Working Pressure：7.0 Bar
Anti-freezing Weather：< (-)40 ℃
Warranty：5years
Packing：Standard Export Packing
Payment Term：TT
Other free services：Free installation manual in Enalish,put logo on tank
Delivery Time：Delivery time within 10 days after receiving deposit
Split Heat Pipe Solar Water Heater-Working Principle：
The solar collector absorbs solar energy and transmits it to the solar water heater tank through circulation
When the temperature of the collector reaches the set value, the controller starts the circulation pump automatically
The circulation pump makes heat-conducting liquid circulate automatically
The heat-conducting liquid transfers heat to water by lower heat exchanger in the water tank.
When the temperature difference between solar collector and heat pipe solar water heaters tank doesn’t reach the set value, the circulation
pump will be shut automatically
In case the temperature of the water tank does not reach max, Electric heating element will start to work automatically
Specialty：
The solar collector can be installed on the roof and the water tank can be installed in the attic or basement.
Only the solar collector on the roof has no water tank, which is small and beautiful.
It can connect with water tap and work automatically with pressure0.6Mpa, bringing enjoyable washing experience.
Safety: P/T valve would release pressure and temperature to protect tank.
